General waste incinerator Chamber capacity 0.36m3

Incinerators must be able to support different power sources (PV solar system , diesel Electric generator , local or compound mini-scale grid).Each unit shall include a complete vertical exhaust and stack system, including the following features: • Steel construction. Packing Details Serie No. Part Name Size(M) Weight(Kgs) 01 Incinerator Mainbody 1.8 x 1.2 x 1.7(LxWxH) 2560 02 Somke Filter Chamber Dia.0.7 x Length 0.8 300 03 Chimney Dia.0.25 x Length 2.5 60 04 Chimney Dia.0.25 x Length 2.5 60 05 Oil Tank Dia.0.7 x Length 1.0 20 Total 5.2 CMB 3000 Kgs • Refractory lining in the lower section. • The exit height of the stack shall be not less than a range of 3-12 metres above ground level depending on the capacity of the incinerator unit. • The diameter of the stack shall be selected by the Contractor to deliver an exhaust exit velocity of not less than 10 metres per second vertically upwards when at full scale operation. • An emission stack sampling port shall be included immediately above the secondary chamber. Containerization The proposed incinerators shall be able to be completely packed into a series of 20ft export standard sea containers. Warranty period: “Warranty will be as per the UNOPS ‘contracts for the provision of goods’ under section 4.5 of the ‘general conditions of contract’ 4.5 WARRANTIES: Unless otherwise specified in the Contract, in addition to and without limiting any other warranties, remedies or rights of UNOPS stated in or arising under the Contract, the Contractor warrants and represents All incinerators shall meet the following emission and operating standards: • Combustion efficiency (C.E.) shall be at least 99.0% • The combustion efficiency shall be computed as follows: o C.E = (CO2 X 100) / (%CO2 +%CO)
